泵體(tǐ)電(diàn)機直連式,結構緊湊;泵體(tǐ)設置加強筋,外(wài)形美觀。
采用CFD水力模型優化設計,有效提高了泵效率。
過流部件的模具采用數控成型,保證了部件的尺寸精度及表面的光潔度。
采用FEM優化設計,複核零件的結構設計合理性及抗載荷要求。
效率指标符合國家标準GB 18613的能效标準絕緣等級F級。
規格、型号 | 參數 | 口徑 | 流量 | 功率KW |
XBD3.3/5G-GDL | 5 | 33 | 50 | 5.5 |
XBD4.5/5G-GDL | 5 | 45 | 50 | 4 |
XBD6.0/5G-GDL | 5 | 60 | 50 | 5.5 |
XBD7.5/5G-GDL | 5 | 75 | 50 | 7.5 |
XBD9.0/5G-GDL | 5 | 90 | 50 | 7.5 |
XBD10.5/5G-GDL | 5 | 105 | 50 | 11 |
XBD12.0/5G-GDL | 5 | 120 | 50 | 11 |
XBD13.5/5G-GDL | 5 | 135 | 50 | 15 |
XBD15.0/5G-GDL | 5 | 150 | 50 | 15 |
XBD7.2/10G-GDL | 10 | 72 | 80 | 18.5 |
XBD8.4/10G-GDL | 10 | 84 | 80 | 15 |
XBD9.6/10G-GDL | 10 | 96 | 80 | 15 |
XBD10.8/10G-GDL | 10 | 108 | 80 | 18.5 |
XBD12.5/10G-GDL | 10 | 125 | 80 | 22 |
XBD6.0/10G-GDL | 10 | 60 | 80 | 11 |
XBD13.5/10G-GDL | 10 | 135 | 80 | 30 |
XBD14.5/10G-GDL | 10 | 145 | 80 | 30 |
XBD4.2/15G-GDL | 15 | 42 | 80 | 11 |
XBD5.8/15G-GDL | 15 | 58 | 80 | 18.5 |
XBD7.0/15G-GDL | 15 | 70 | 80 | 18.5 |
XBD8.4/15G-GDL | 15 | 84 | 80 | 18.5 |
XBD14.0/15G-GDL | 15 | 140 | 80 | 37 |
XBD9.8/15G-GDL | 15 | 98 | 80 | 22 |
XBD11.2/15G-GDL | 15 | 112 | 80 | 22 |
XBD12.6/15G-GDL | 15 | 126 | 80 | 30 |
XBD5.6/20G-GDL | 20 | 56 | 100 | 18.5 |
XBD7.0/20G-GDL | 20 | 70 | 100 | 22 |
XBD8.4/20G-GDL | 20 | 84 | 100 | 30 |
XBD9.8/20G-GDL | 20 | 98 | 100 | 30 |
XBD10.5/20G-GDL | 20 | 105 | 100 | 37 |
XBD11.0/20G-GDL | 20 | 110 | 100 | 45 |
XBD12.6/20G-GDL | 20 | 126 | 100 | 37 |
XBD13.5/20G-GDL | 20 | 135 | 100 | 45 |
XBD14.0/20G-GDL | 20 | 140 | 100 | 45 |
XBD14.7/20G-GDL | 20 | 147 | 100 | 55 |
XBD8.5/25G-GDL | 25 | 85 | 100 | 37 |
XBD9.5/25G-GDL | 25 | 95 | 100 | 45 |
XBD10.0/25G-GDL | 25 | 100 | 100 | 45 |
XBD12.2/25G-GDL | 25 | 122 | 100 | 75 |
XBD12.5/25G-GDL | 25 | 125 | 100 | 55 |
XBD6.0/30G-GDL | 30 | 60 | 100 | 30 |
XBD8.0/30G-GDL | 30 | 80 | 100 | 37 |
XBD9.5/30G-GDL | 30 | 95 | 100 | 45 |
XBD10.0/30G-GDL | 30 | 100 | 100 | 45 |
XBD12.0/30G-GDL | 30 | 120 | 100 | 55 |
XBD11.5/30G-GDL | 30 | 115 | 100 | 45 |
XBD13.5/30G-GDL | 30 | 135 | 100 | 55 |
XBD14.0/30G-GDL | 30 | 140 | 100 | 75 |
XBD15.0/30G-GDL | 30 | 150 | 100 | 75 |
XBD20.0/30G-GDL | 30 | 200 | 100 | 132 |
XBD7.2/35G-GDL | 35 | 72 | 150 | 75 |
XBD6.0/45G-GDL | 45 | 60 | 150 | 37 |
XBD8.0/45G-GDL | 45 | 80 | 150 | 55 |
XBD9.5/45G-GDL | 45 | 95 | 150 | 55 |
XBD11.0/45G-GDL | 45 | 110 | 150 | 75 |
XBD12.0/45G-GDL | 45 | 120 | 150 | 75 |
XBD13.0/45G-GDL | 45 | 130 | 150 | 90 |
XBD14.0/45G-GDL | 45 | 140 | 150 | 90 |
XBD16.0/45G-GDL | 45 | 160 | 150 | 110 |
XBD16.2/45G-GDL | 45 | 162 | 150 | 132 |
